A125

3 mB Download .PDF

SIDE VIEW

FRONT VIEW

Base

Option		IMT
Undercarriage length / widening range / shoe	mm	CAT 4660 / 2550 – 3650 / 600
	in	182 / 100 – 144 / 23,6
Engine type		CAT C 7,1 Tier 4F
Power		129KW (173 HP) @1900 rpm

Rotary

Option		IMT
Installed torque	kNm	122
	lbf ft	90000
Working speed		7,5 – 27
Discharge speed		45 – 120

Winches

Option		IMT
Main winch pull force	kN	122
	lbf	27655
Main winch speed	m/min	90
	ft/min	295
Main winch Cable diameter	mm	22
	in	–
Auxiliary winch pull force	kN	60
	lbg	13490
Auxiliary winch Speed	m/min	90
	ft/min	295
Auxiliary winch Cable diameter	mm	15
	in	–

Crowd System

Option		IMT
Kelly crowd push	kN	100
	lbf	22485
Kelly crowd pull	kN	165
	lbf	37095
Stroke	mm	3325
	in	131

Mast

Option		IMT
Mast raking forward	degree	5°
Mast side raking	degree	+/- 5°
Mast raking backwards	degree	15°
Pile max diameter	mm	1500
	in	60

Kelly bar

Option		IMT
Standard		4/38
Options available		4/30 – 5/47
Operating Weight w/standard kelly bar	t(metric)	35
	lbs	77170

Special applications for this machine

LCA VERSION
